Double Coated Pressure Sensitive Adhesive Foam tape


Lixin 6608G is a strong, high performance double-sided foam bonding tape. The product is black. The Polyethylene foam is predominantly closed celled. An acrylic pressure sensitive adhesive is coated on both sides, and the product has a white, Polycoat paper release liner. The material can be supplied with a film liner facilitating automated application




High Performance PE Double Sided Foam Adhesive Tape

PRODUCT DESCRIPTION

Lixin 6608G is a strong, high performance double-sided foam bonding tape. The product is black. The Polyethylene foam is predominantly closed celled. An acrylic pressure sensitive adhesive is coated on both sides, and the product has a white, Polycoat paper release liner. The material can be supplied with a film liner facilitating automated application





Colours

Black



Adhesive

Acrylic


Liner

Paper release liner can be supplied with film liner



Carrier

PE Foam


Thickness
0.8,1.0mm



Availability
Asia/EU/NA
Currently available in all regions, subject to supply considerations.


APPLICATIONS
·Lens edging pads.
·Automotive mirror mounting.

·Automotive emblem mounting.













PRODUCT BENEFITS

·Pre-determined dimensional sealant reduces waste / clean to use.
·No known hazards associated with this product.
·Suitable for indoor and outdoor environments.
·Resistance to abrasion, corrosion and moisture.
·Very good ultraviolet {UV} light resistance.
·Paper release liner, reducing dimensional change during application.
·Good resistance to dilute acids and alkalis.
·Coated on both sides with a high quality pressure sensitive acrylic adhesive.
·Minimum 20% compression required to effect a water seal.
·Shelf life of 1 year from date of dispatch.
·Application temperature: +10°C to +40°C.
·Service temperature: -40°C to +120°C.
·Maximum recommended weight loading of 15 g/cm².






product Backing adhesive Total Thickness Initial Tack Peel Adhesion Holding power
Replace
Brand tape
(um) (mil) (#) N/in ASTM D-3330       (oz/in)
65010 EVA Solvent Acrylic 1500 6.0  12↑ 12↑ 36 24hour↑/80℃ /
65015 EVA Solvent Acrylic 2000 8.0  12↑ 12↑ 36 24hour↑/80℃ /
65020 EVA Solvent Acrylic 2500 10.0  12↑ 12↑ 36 24hour↑/80℃ /
66015 PE foam Solvent Acrylic 150 6.0  18↑ 20↑ 60 24hour↑/80℃ Sekisui5215PSB/Nitto57115
66020 PE foam Solvent Acrylic 200 8.0  18↑ 20↑ 60 24hour↑/80℃ Sekisui5200PS/Nitto57120
66025 PE foam Solvent Acrylic 250 10.0  18↑ 20↑ 60 24hour↑/80℃ Sekisui5225PSB/Nitto57125
66025T PE foam Solvent Acrylic 250 10.0  16↑ 15/10↑ 45/30 24hour↑/80℃ tesa62945
66030 PE foam Solvent Acrylic 300 12.0  18↑ 20↑ 60 24hour↑/80℃ Sekisui5230PSB/teraoka7813
66030T PE foam Solvent Acrylic 300 12.0  16↑ 15/10↑ 45/30 24hour↑/80℃ tesa62946
66040 PE foam Solvent Acrylic 400 16.0  18↑ 20↑ 60 24hour↑/80℃ Sekisui5240NSB
66050 PE foam Solvent Acrylic 500 20.0  18↑ 20↑ 60 24hour↑/80℃ /
66060 PE foam Solvent Acrylic 600 24.0  18↑ 20↑ 60 24hour↑/80℃ Sekisui5260NSB
66080 PE foam Solvent Acrylic 800 32.0  18↑ 20↑ 60 24hour↑/80℃ Sekisui5290NSB
66100 PE foam Solvent Acrylic 1000 40.0  18↑ 20↑ 60 24hour↑/80℃ Sekisui52110NSB
66100V(Low voc) PE foam Solvent Acrylic 1000 40.0  18↑ 20↑ 60 24hour↑/80℃ /
66150 PE foam Solvent Acrylic 1500 60.0  18↑ 20↑ 60 24hour↑/80℃ /
66200 PE foam Solvent Acrylic 2000 80.0  18↑ 20↑ 60 24hour↑/80℃ /
66300 PE foam Solvent Acrylic 3000 120.0  18↑ 20↑ 60 24hour↑/80℃ /
