General Purpose Double Sided Tissue Tape
Lixin6310 is a general-purpose double sided tape based on a light weight tissue paper. The tape is coated on both sides with a high tack permanent acrylic adhesive system, with a 110gr. white siliconised paper release liner. 6310 has a 0.1 mm total thickness and is recommended for a variety of permanent bonding, mounting and splicing applications where high tack and adhesion are required.
General Purpose Double Sided Tissue Tape
PRODUCT REFERENCE
Lixin6310 is a general-purpose double sided tape based on a light weight tissue paper. The tape is coated on both sides with a high tack permanent acrylic adhesive system, with a 110gr. white siliconised paper release liner. 6310 has a 0.1 mm total thickness and is recommended for a variety of permanent bonding, mounting and splicing applications where high tack and adhesion are required.
|
Colours White
|
|
Adhesive Acrylic
|
|
Liner White siliconised paper release liner on two sides
|
|
Carrier Tissue
|
|
Thickness 0.1 mm
|
|
Availability
|
|
APPLICATIONS ·Bonds a wide variety of foams and gaskets. ·Suitable for bonding cloth. ·Core starting of films, foils and paper webs. ·End tabbing of films, foils and papers. ·Fascia assembly. ·Mounting leather. ·Bonding of nameplates. ·Miscellaneous bonding, mounting and holding applications where a thin and flexible bond is required. ·Suitable for bonding a wide variety of similar and dissimilar substrates such as glass, metal and plastics.
|
|
PRODUCT BENEFITS
·Easily tearable by hand.
|
| product | Backing | adhesive | Total Thickness | Initial Tack | Peel Adhesion | Holding power |
Replace
Brand tape
|
||
| (um) | (mil) | (#) | N/in | ASTM D-3330 (oz/in) | |||||
| 6306R | Tissue | Synthetic Rubber | 60 | 2.4 | 8↑ | 12↑ | 43 | 0 ~ +65 | / |
| 6307R | Tissue | Synthetic Rubber | 70 | 2.8 | 10↑ | 13↑ | 47 | 0 ~ +65 | / |
| 6308R | Tissue | Synthetic Rubber | 80 | 3.2 | 10↑ | 15↑ | 54 | 0 ~ +65 | / |
| 6309R | Tissue | Synthetic Rubber | 90 | 3.5 | 10↑ | 15↑ | 54 | 0 ~ +65 | / |
| 6310R | Tissue | Synthetic Rubber | 100 | 3.9 | 12↑ | 17↑ | 61 | 0 ~ +65 | / |
| 6306 | Tissue | Solvent Acrylic | 60 | 2.4 | 8↑ | 12↑ | 43 | 24hour↑/100℃ | 3M467 |
| 6308 | Tissue | Solvent Acrylic | 80 | 3.2 | 10↑ | 13↑ | 47 | 24hour↑/80℃ | / |
| 6309 | Tissue | water-base Acrylic | 90 | 3.6 | 14↑ | 12↑ | 43 | 24hour↑/80℃ | / |
| 6310 | Tissue | Solvent Acrylic | 100 | 4 | 14↑ | 12↑ | 43 | 24hour↑/80℃ | / |
| 6012 | Tissue | Solvent Acrylic | 120 | 4.8 | 16↑ | 18↑ | 54 | 24hour↑/120℃ | tesa60976 |
| 6314 | Tissue | Solvent Acrylic | 140 | 5.3 | 18↑ | 20↑ | 60 | 24hour↑/120℃ | tesa68646 |
| 6314S | Tissue | Solvent Acrylic | 140 | 5.3 | 18↑ | 22↑ | 60 | 24hour↑/80℃ | tesa68626 |
| 6315 | Tissue | Solvent Acrylic | 150 | 5.7 | 18↑ | 20↑ | 60 | 24hour↑/100℃ | tesa60980/3M55230/teraoka777 |
| 6315P | Tissue | Solvent Acrylic | 150 | 5.7 | 18↑ | 20↑ | 60 | 24hour↑/120℃ | Nitto500/3M9448/ G9000/T4000 |
| 6315S | Tissue | Solvent Acrylic | 150 | 5.7 | 18↑ | 20↑ | 60 | 24hour↑/120℃ | Nitto500/3M9448/ G9000/T4000 |
| 6316 | Tissue | Solvent Acrylic | 160 | 6.08 | 18↑ | 20↑ | 60 | 24hour↑/120℃ | Nitto5015E |
| 6314V(Low voc) | Tissue | Acrylic | 150 | 5.7 | 18↑ | 18↑ | 54 | 24hour↑/80℃ | Nitto510 |
| 6315V(Low voc) | Tissue | Acrylic | 150 | 5.7 | 18↑ | 18↑ | 54 | 24hour↑/80℃ | Nitto512 |
| 6325V(Low voc) | Tissue | Acrylic | 250 | 9.5 | 20↑ | 20↑ | 60 | 24hour↑/80℃ | Nitto515 |
