Yellow green PVC electrical insulating tape
Yellow green PVC electrical insulating tape is a lead free PVC electrical insulation tape with a cross-linked solvent based rubber-resin adhesive suitable for general electrical insulation work.
Yellow green PVC electrical insulating tape
PRODUCT REFERENCE
Yellow green PVC electrical insulating tape is a lead free PVC electrical insulation tape with a cross-linked solvent based rubber-resin adhesive suitable for general electrical insulation work.
|
Colours Black, White, Red, Blue, Yellow, Yellow/Green, Transparent, Grey
|
|
Adhesive Rubber Resin
|
|
Carrier Soft PVC
|
|
Thickness 0.13/0.15/0.18 mm
|
|
APPLICATIONS ·Colour coding and insulation of electrical cabling ·Colour coding components, intermediate stock and finished goods during manufacture ·Cableharnessing, insulation, abrasion protection for OEM companies in household appliances market ·Masking off during chemical and electro-plating ·Masking and protection of aircraft portholes during manufacture ·Masking off aircraft landinggear when cadmium plating
|
|
PRODUCT BENEFITS ·It is easy to unwind and tear so reduces the risk of RSI. Ideal for indoor and outdoor use as it’s water and UV resistant ·The extreme conformability enables the tape to be easily applied to awkward surfaces. Used for insulating cables, harnessing and colour coding. ·It is available in a wide range of colours, width and lengths.
|
|
Features ·Flame Retardant ·Self-extinguishing ·Easy unwind and easy tear ·Flexible and Conformable ·Water Resistant ·UV Resistant ·Abrasion Resistant ·Non-corrosive adhesive |
|
|
| product | Total Thickness | Carrier | Backing Thickness | Adhesion to steel | Adhesion to Backing |
Tensile Strength |
Elongation
(%)
|
Dielectric Strength | Max.Continuous Operating Temperature |
| (um) | (um) | N/cm | N/cm | N/cm | % | kv/mm | |||
| 21116 | 110 | PVC Flim | 95 | 1.2 | 1.0 | 18 | 220 | 45 | 80°C/176°F |
| 21126 | 120 | PVC Flim | 105 | 1.2 | 1.0 | 19 | 220 | 45 | 80°C/176°F |
| 21G66 | 130 | PVC Flim | 115 | 1.2 | 1.0 | 21 | 230 | 45 | 80°C/176°F |
| 21156 | 150 | PVC Flim | 135 | 1.2 | 1.0 | 23 | 250 | 45 | 80°C/176°F |
| 21166 | 165 | PVC Flim | 150 | 1.2 | 1.0 | 25 | 250 | 43 | 80°C/176°F |
| 21176 | 175 | PVC Flim | 160 | 1.2 | 1.0 | 27 | 250 | 43 | 80°C/176°F |
| 21556 | 180 | PVC Flim | 165 | 1.2 | 1.0 | 28 | 250 | 43 | 80°C/176°F |
| 21196 | 190 | PVC Flim | 175 | 1.2 | 1.0 | 29 | 250 | 43 | 80°C/176°F |
| 21206 | 200 | PVC Flim | 185 | 1.2 | 1.0 | 30 | 250 | 43 | 80°C/176°F |
