High Temperature Resistant Acrylic Clean Removal Filament Tape
Lixin5694 is a transparent and high strength filament tape. Glass fiber contributes higher tensile strength and improved pressure-sensitive adhesive delivers high viscosity andtensile strength; high resistance to abrasion; impact resistance and high holding power.
High Temperature Resistant Acrylic Clean Removal Filament Tape
PRODUCT DESCRIPTION
Lixin5694 is a transparent and high strength filament tape. Glass fiber contributes higher tensile strength and improved pressure-sensitive adhesive delivers high viscosity andtensile strength; high resistance to abrasion; impact resistance and high holding power.
|
Adhesive
Acrylic adhesive
|
|
Liner None
|
|
Carrier PET Fiberglass reinforced |
|
Thickness 0.16 mm |
|
APPLICATIONS ·Suitable for transformers, electrical equipmentand ABS board,coilsand motor parts strapping and fixing ·Packaging, Tabbing , Splicing, Binding & Harnessing, Coil Wrap Banding, Bundling
|
|
PRODUCT BENEFITS
·Industrial grade fiberglass reinforced strapping tape |
|
Clean Removal Mono Filament Tape Technical Data Sheet |
|||||||||||
| Product | Adhesive | Backing | Color | Total Thickness | Peel Adhesion | Tensile Strength | Elongation | Tem range | |||
| mm | mils | N/25mm | Ibs/in | N/25mm | Ibs/in | ℃ | |||||
| Lixin-5602 | Synthetic Rubber | PET-Fiberglass | Clear | 0.12 | 4.7 | 15 | 54 | 500 | 112 | 3% | -10-80 |
| Lixin-5615 | Synthetic Rubber | PET-Fiberglass | Clear | 0.14 | 5.5 | 16 | 58 | 850 | 191 | 3% | -10-80 |
| Lixin-5516 | Synthetic Rubber | BOPP-Fiberglass | Clear | 0.16 | 6.3 | 16 | 58 | 700 | 157 | 3% | -10-80 |
| Lixin-5698 | Synthetic Rubber | PET-Fiberglass | Clear | 0.18 | 7.1 | 22 | 79 | 1050 | 236 | 5% | -10-80 |
| Lixin-5607 | Synthetic Rubber | PET-Fiberglass | Milk white | 0.16 | 6.3 | 22 | 79 | 950 | 214 | 3% | -10-80 |
| Lixin-5609 | Synthetic Rubber | PET-Fiberglass | Clear | 0.2 | 7.9 | 20 | 72 | 1500 | 337 | 5% | -10-80 |
| Lixin-5696 | Synthetic Rubber | PET-Fiberglass | Clear | 0.23 | 9.1 | 13 | 47 | 2100 | 472 | 5% | -10-80 |
| Lixin-5614 | Synthetic Rubber | PET-Fiberglass | Clear | 0.17 | 6.7 | 15 | 54 | 900 | 202 | 28%±2% | -10-80 |
| Lixin-5614A | Solvent Acrylic | PET-Fiberglass | Clear | 0.18 | 7.1 | 15 | 54 | 1750 | 393 | 28%±2% | -5-100 |
